A cost effective 26dB masthead amplifier suitable for digital, analogue, or HDTV reception. The unit is able to accept signals from separate UHF and VHF antennas, or UHF/VHF combination antennas, and output the amplified signal down a single cable. Features separate VHF and UHF gain controls, F-type connections, weatherproof plastic housing and optional FM trap. Supplied with power injector, PAL Male to F-Male lead, 2 x PAL-Female to F-Male adaptors and power supply.

Specifications:
• UHF gain: 26dB
• VHF gain: 18dB
• Current consumption: 80mA
• Power supply: 15VDC
• Noise figure: UHF 1.5dB / VHF 2dB
• Return loss: In 10, Out 8
• HDTV Compliant
• Dimensions: 125(W) x 102(H) x 45(D)mm
SKU AM-LT3275
Model # LT3275
Barcode # 9319236976791
