Specifications
Bi Colour Red Green
Size (mm) 10 10
Lens Diffused Diffused
Viewing Angle (Degrees) 75 75
Wavelength (nm) 625 570
IF Typical (mA) 20 20
VF Typical (V) 2.0 2.1
IV Typical (mcd) 10 10
IF Max Continuous (mA) 30 30
Preferred Series Resistor (ohms)
5VDC 150 150
9VDC 360 360
12VDC 510 510
SKU AM-ZD0255
Model # ZD0255
Barcode # 9319236890325
