Pitch: 9.5mm
Barrier Material: Thermoplastic (UL=94V-0), Black
Terminals: Tint Plated Brass (Standard)
Screws: Nickel Plated Steel
Wire Range AWG: 12-22 STR
Rating: 25 Amperes, 300VAC
Cover Material: PC
Insulation withstands voltage AC 2000V/Min
Insulation Resistance: 500Mohm or more at 500V
9.5mm Pitch
Pole HD-12-? P HD-12-? PH
A (Px9.5)+1.4 (P+2)*9.5+1.4
B (P-1)*9.5 (P+1)*9.5
SKU AM-HM3164
Model # HM3164
Barcode # 9319236903988
