Dimensions 1.57” x 0.79” x 1.50” (40 x 20 x 38.1mm)
Product Weight 1.73oz. (49g)
Output Shaft Style 25 Tooth 3F Spline
Voltage Range 6.6V - 7.4V
No-Load Speed (6.6V) 0.19sec/60°
No-Load Speed (7.4V) 0.17sec/60°
Stall Torque (6.6V) 138.9 oz/in. (10.0 kg-cm)
Stall Torque (7.4V) 145.9 oz/in. (10.5 kg-cm)
Pulse Amplitude 3-5V
Operating Temperature -20 to +60°C
Direction w/ Increasing PWM Signal Counter Clockwise
Motor Type Coreless Motor
Potentiometer Drive Indirect Drive
Output Shaft Support Single Ball Bearing
Gear Type Straight Cut Spear
Gear Material Metal
Wire Length 12"
SKU FUTS3071HV
Barcode # FUTS3071HV
Brand Futaba
Shipping Weight 0.2000kg
