Specification
Output:
EZRUN-60A: Continuous 60A, burst 380A.
EZRUN-35A: Continuous 35A, burst 190A.
Input: 4-9 cells NiMH/NiCd or 2-3S LiPo.
BEC: 6V/1.5A (Linear mode built-in BEC).
Resistance:
EZRUN-60A: 0.0007 Ohm.
EZRUN-35A: 0.0015 Ohm.
Motor Supported: Sensorless Brushless Motor.
Suitable Motor: * Note #1
EZRUN-60A:
With 4-6 cells NiMH/NiCd or 2S Lipo: On-Road=5.5T, Off-Road=8.5T;
With 6-9 cells NiMH/NiCd or 3S Lipo: On-Road=8.5T, Off-Road=13T;

EZRUN-35A:
With 4-6 cells NiMH/NiCd or 2S Lipo: On-Road=9T, Off-Road=12T;
With 6-9 cells NiMH/NiCd or 3S Lipo: On-Road=12T, Off-Road=18T;

Suitable Car: 1/12 and 1/10 on-road and off-road sport.
Size: 31.5mm(L) * 27.5mm(W) * 24mm(H).
Weight:
EZRUN-60A: 32g (Without wires).
EZRUN-35A: 30g (Without wires).

* Note #1: These listed T numbers are available for 3650 sized brushless motor (?=36, L=50)

Features
Compatible with sensorless brushless motors.
High quality components, big current endurance.
Excellent start-up, acceleration and linearity features.
Plenty of programmable items, suitable for various of chassis's, tires and racing tracks.
Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection.
Internal timing can be changed easily to make the ESC suitable for various of motors.
Easily programmed with the SET button, LED Program Box, Multifunction LCD Program Box and USB Link Software.

SKU HW81010190
Brand HOBBYWING
