SPECIFICATION:
-  Wingspan: 1,238 mm (48.75 in).
-  Length: 1,650 mm (64.96 in).
-  Weight: 7.2 – 7.4kg  (15.84-16.28 lbs).
-  Wing area: 63.2dm2.
-  Wing loading:114g/dm2.
-  Wing type: Boeing 707.54 Span.
-  Gear type: Electric retract gear, size: (92.2 x 51 x 30.6)mm (not included).
   CNC Suspension Metal Struts (included)

Parts listing required (not included):
-  Radio: 9 channels.
-  Servo: 8 standard high torque servos, size: (33 x 17)mm.
             +  2 servos (Futaba BLS 352), size: (39.9 x 20.1 x 37.1)mm canard.
-  Engine: EDF 120mm.
-  Battery: 12S LIPO – 44.4 V.
-  ESC: 160A.

Recommended EDF and Battery set up (not included):
-  Engine: Ducted Fan EDF JETFAN-120 eco Ejets+ HET 800-68-685.
   Battery: 12S LIPO – 44.4 V  ≥ 6000Amh 40C.
Or Engine: Ducted Fan EDF Schubeler DS-86-AXI HDS 120mm + TP 5660-9D motor.
   Battery: 10 – 12S LIPO – 37 – 44.4 V  ≥ 6000Amh 40C.
-  ESC: 160A Phoenix Castle.

NOT INCLUDING ELECTRIC RETRACT GEAR.
ONLY INCLUDING
CNC SUSPENSION METAL STRUTS.
ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM





SKU BH-165
Brand BLACK HORSE AIRCRAFT
Shipping Weight 5.0000kg
