DUALSKY BL motors are precision mechanical masterpieces, are precisely manufactured and have an excellent efficiency. A wide range of motor types offers a drive for almost every application. Series "GA" is specifically designed for large-scale models and offers outstanding performance and a robust stainless steel motor shaft.
  • Designed for 120E to 140E Class 3D airplanes
  • High strength stainless steel shaft
  • Brushless
  • 30cc - 35cc class
RPM/KV
180 RPM/V
Weight w/o accessories
585g
Outer diameter
89mm
Length w/ mounts
75.2mm
Length (Overall)
118mm
Diameter of shaft
12mm (internal)
8mm (output)
Mounting holes pitch
71 - 75mm
Idle current @ 10V
1.1A
Nominal Voltage
44.4V, 12S LiPo
Peak Power (15s)
3300W (5.5HP)
Bursts current (15s)
75A
Propeller
18x10, 19x10, 20x10
Weight of sports airplane
Up to 8kg
Weight of 3D airplane
Up to 5.5kg
Slots, Poles
24, 28
SKU DSXM51555
Brand Dualsky
