This tuning combo from Dualsky offers a XM2834CA-9 Motor and XC-45-Lite ESC.  This package will suit 480-size RC planes or helicopters.  It is compatible with the V2 programming card.

  • Comes with XM2834CA-9 motor and XC-45-Lite ESC
  • Ideal for 480-size RC planes or helicopters
  • Compatible with the V2 programming card
Motor RPM/V (KV)
1000
Motor Stator Diameter (mm)
28
Motor Magnet Length (mm)
8
Motor Shaft Diameter (mm)
4
Motor Mounting Holes Pitch
19/25
Motor Weight (g)
74
Motor Resistance (Ri)(mOhm)
102
Motor Idle Current (Io) @10V (A)
0.75
Motor No.of Cells (LiPo)
2.3
Motor Max. Efficiency Current (A)
14
Motor Max. Burst Current (15s)(A)
24
Motor Approximate Max. Power (15s) (W)
250
Motor Input Connectors
DB3
Motor Recommended ESC
XC2512BA
Motor Prop. Range
8x5, 12x6
Motor App. Class
480-size, 10-class
ESC Dimensions (L x W x D) (mm)
67x 25x 7
ESC Weight, with wires (g)
38
ESC Number of Cells (NiXX)
5-9 cells, 6-10.8V
ESC Number of Cells (LiPo)
2-3s, 7.4-11.1V
ESC Resistance(Ri)(Ohm)
0.0026
ESC Max Cont. Current & Max Cont.Output
45A, 500W
ESC Max Burst Current & Max Burst Output
60A, 666W
ESC BEC / Dissipative Power
5.2V/3A (Linear)
ESC Programmable
Throttle + ProgCARD V2
ESC Signal Wire
300MM JR
SKU DSTC.3A.480
Barcode # 6941047191075
Brand Dualsky
Shipping Weight 0.0500kg
