The Dualsky 15E tuning combo consists of a 990Kv motor and a 45A ESC. It will suit .10-.15 class RC planes or helicopters.

XM3536CA-8 Motor Specification:

KV
990RPM/V
Stator Diameter
28
Magnet Length
14
Shaft Diameter
4
Mounting Holes Pitch
19/25
Weight
103g
Resistance (Ri)
46mOhm
Idle Current (Io) @10V
1.27A
No.of Cells (LiPo)
2-3
Max. Efficiency Current
21A
Max. Burst Current (15s)
32A
Max. Power (15s)
350W
Input Connectors
DB3
Recommended ESC
XC3012BA
Prop. Range
10x5, 13x6

XC-45-Lite ESC Specification:

Dimensions
67x 25x 7mm (L x W x D)
Weight
38g (with wires)
Number of Cell
NiXX 5-9 cell, 6-10.8V LiPo 2-3s, 7.4-11.1V
Resistance(Ri)(Ohm)
0.0026
Max Cont. Current & Max Cont.Output
45A, 500W
Max Burst Current & Max Burst Output
60A, 666W
BEC / Dissipative Power
5.2V/3A (Linear)
Programmable
Throttle + ProgCARD V2
Signal Wire
300MM JR
SKU DSTC.3A.15E
Barcode # 6941047191082
Brand Dualsky
Shipping Weight 0.0500kg
